With the Clemens TUNNEL spraying technology, you can reduce drifting by up to 99%.

Using the recycling technology, material that is not taken up flows back into the tank. The valuable spraying agents are filtered carefully, pumped back into the tank and re-used. This is an enormous benefit to the environment and to your vineyard! The innovative machines apply the agent evenly from all sides and ensure optimal application. With a very wide track and telescopic balancing, they operate very smoothly at maximum speed.

Product Video


  • 35% - 40% less crop protection agent required
  • up to 99% less drifting
  • more crop protection agents to choose from
  • less distance to be maintained from open water
  • protection of the user
  • very high level of agent application with all sprayings
  • BBA certified and included in the register of loss-reducing machines

Model Specifications

  AN 2 N 2 S 3
Weight: 450 kg 1,100 kg 1,700 kg
Tunnel length: 1,250 mm 1,250 mm 1,250 mm
Max. row height: 2,200 mm 2,200 mm 2,200 mm
Width adjustment: 200 - 1,100 mm 200 - 1,100 mm 200 - 1,100 mm
Minimum row width: 1,700 - 2,400 mm 1,700 - 2,500 mm 1,800 - 2,500 mm
